Get reliable performance and maximum protection with NAPA Gold Filters. Designed for cars, trucks, heavy equipment, and more, NAPA Gold offers a complete line of oil, air, fuel, cabin air, hydraulic, and transmission filters. With wide coverage across passenger, commercial, agricultural, industrial, and powersports applications, NAPA Gold delivers premium filtration you can trust.
Upgrade to NAPA Gold for longer engine life, better efficiency, and superior performance.
Specifications
Brand: NAPA
Sub Brand: Gold
Gasket or Seal Included: Yes
VMRS Code: 44002001
Fluid Type: Diesel
Quality Level: Better
Filter I.D. (mm): 20.574 mm
Gasket Included: Yes
Outer Diameter: 4.125 in
Bottom Inside Diameter: 0.81 in
Filter Media Material: Cellulose
Body Length: 7.18 in
Fuel Filter I.D. (mm): 20.574 mm
Height: 7.17 in
SDS Required: No
Fuel Filter I.D. (Inches): 0.81 in
Manufacturer Part Number: PF46081
Bottom Outside Diameter: 4.125 in
Weight: 0.85 lbs
Fuel Filter O.D. (mm): 104.77 mm
Type: Fuel/Water Separator Element
Contents: Fuel Filter
Fuel Filter O.D. (Inches): 4.125 in
Length: 7.18 in
Contains VOCs: No
New Or Remanufactured: New
Filter Type: Cartridge
Application: Kenworth, Peterbilt Trucks
Vehicle Fitment Guide
Make / Model / Year(s)
Chevrolet / C8500 / 2008-2009
Chevrolet / C7500 / 2003-2004
Ford / F800 / 1967-1970
Freightliner / Coronado / 2011-2011
Freightliner / FLT86 / 1987-1988
Freightliner / M2-106 / 2002-2004
Freightliner / M2-106 / 2007-2007
Kenworth / W900 / 1999-2000
Kenworth / W900 / 2002-2016
Kenworth / W900 / 2022-2022
Kenworth / T660 (Non-US/Canada) / 2008-2016
Kenworth / T660 (Non-US/Canada) / 2019-2020
Kenworth / T880 / 2015-2017
Kenworth / T880 / 2019-2020
Kenworth / T880 / 2023-2024
Kenworth / T680 / 2013-2017
Kenworth / T680 / 2021-2021
Kenworth / T800 / 2010-2017
Kenworth / T800 / 2019-2019
Kenworth / T800 / 2021-2024
Kenworth / W990 / 2024-2024
Peterbilt / 367 / 2008-2018
Peterbilt / 367 / 2020-2020
Peterbilt / 587 / 2011-2018
Peterbilt / 520 / 2017-2018
Peterbilt / 520 / 2020-2020
Peterbilt / 389 / 2015-2018
Peterbilt / 389 / 2020-2020
Peterbilt / 389 / 2022-2022
Peterbilt / 579 / 2014-2019
Peterbilt / 384 / 2011-2017
Peterbilt / 365 / 2011-2018
Peterbilt / 365 / 2020-2020
Peterbilt / 567 / 2014-2014
Peterbilt / 567 / 2016-2017
Peterbilt / 567 / 2019-2019
Peterbilt / 320 / 2018-2018
